Introduction to RF Design Theory and Principles - RAHRF201

Introduction to RF Design Theory and Principles - RAHRF201

Preparing for Apple, Broadcom, Qualcomm , Skyworks and other RF interviews

上次更新 5/2020

英语 [自动]

7 个章节 • 63 个讲座 • 总时长 9 小时 34 分钟

https://www.udemy.com/course/rf-engineeer-design-theory-and-principles-rahrf201/

你将会学到的

Power in AC circuits (Detailed explanation including average power, complex power, maximum power transfer and power in matched RF systems.

A brief review of MOS transistor (DC and AC analysis)

Nonlinearity in RF systems (Everything you need to know about non-linearity is explained in details including numerical examples.)

Noise including device noise, Noise PSD, Input referred noise and Noise Figure

Sensitivity and Dynamic range in RF systems

RLC passive circuits

要求

RAHRF101

Electrical and Electronics Engineering Basics (Bachelor's level circuit and system analysis)

You should be familiar with basic level Fourier transform, frequency spectrum and circuit analysis.

说明

Rahsoft RF Certificate Program Available courses are as below:



List of courses Available toward RF Certificate



RF Fundamentals, Basic Concepts Components RAHRF101

Modulation and Digital Communications in RF RAHRF152

RF Design Theory and Principles RAHRF201

Advance Design System (ADS) Basics and Applications RAHRF209-L

Receiver, Transmitter and Transceiver Architectures RAHRF409

Low Noise Amplifier (LNA) Design Fundamentals RAHRF526

Low Noise Amplifier (LNA) Design lab using ADS RAHRF526-L

Power Amplifier (PA) Design Fundamentals RAHRF562

Power Amplifier (PA) Design lab using ADS RAHRF562-L





In RAHRF201 you would get deeper into Radio Frequency Design Theory and Principles. The reference book for this course is RF Microelectronics of Behzad Razavi .



At the end of this course the student will have depth knowledge of Radio Frequency principles. The team's main goal while developing the course has been to concentrate more on the concepts in order for students to understand the topics rather than simply providing formulas.



This course has helped Engineers on surviving complicated phone and onsite interviews of Fortune 500 RF Companies and gain salaries on their early careers from 70K~120K. This course is also helpful for Engineers in the industry or technicians which want to change gears towards Radio Frequency.



The above course is taught on campus in groups and now it is being provided online as well for individuals. Rahsoft provides these courses online through Udemy as well as its own website and it counts toward RF Certificate provided through Rahsoft.



Below you can find the topics taught in RF Design Theory and Principles (RAHRF201)



Section2: PowerHave a complete understanding of power in Radio Frequency

Lecture3:Instantaneous and average power

Lecture4:Power Example 1

Lecture5:power and phasor

Lecture6:Power Example 2

Lecture7:Complex power

Lecture8:Complex Power Summary

Lecture9:Power Example 3

Lecture10:Complex Power ADS simulation

Lecture11:Maximum power

Lecture12:Max power ADS simulation

Lecture13:Power and Matching(Preview enabled)

Lecture14:Max Power and Matching Summary

Lecture15:dB, dBm and power gain

Section3:Mos Transistor

Lecture16:MOS Transistor structure and DC characteristics

Lecture17:Small signal

Lecture18:Small signal model

Lecture19:Parasitic cap and fT

Lecture20:ADS FT

Lecture21:MOS Example 1

Section4:Non Linearity

Lecture22:Intro

Lecture23:Harmonic distortion

Lecture24:Gain Compression

Lecture25:Gain Compression ADS example

Lecture26:Harmonic Distortion and Gain Compression Summary

Lecture27:Desensitization(Preview enabled)

Lecture28:Desensitization Example

Lecture29:Intermodulation

Lecture30:Intermodulation IIP3

Lecture31:Intermodulation Example 1

Lecture32:Intermodulation Example 2

Lecture33:Intermodulation Example 3

Lecture34:Cascaded Stages

Section5:Noise

Lecture35:Intro

Lecture36:Device Noise

Lecture37:Input Referred Noise

Lecture38:Input Referred Noise Example

Lecture39:Noise Figure (NF) First Part(Preview enabled)

Lecture40:Noise Figure (NF) Second Part

Lecture41:Noise Figure (NF) Example 1

Lecture42:Noise Figure (NF) Example 2

Lecture43:Noise in Cascaded stages

Lecture44:Noise in Cascaded stages Example

Lecture45:Noise in Passive Reciprocal Circuits

Lecture46:Noise in Passive Reciprocal Circuits Example

Section6:Sensitivity and Dynamic Range

Lecture47:Sesitivity(Preview enabled)

Lecture48:Sensitivity Example

Lecture49:Dynamic Range

Lecture50:Dynamic Range Example

Section7:RLC circuit

Lecture51:RLC resonance Circuits

Lecture52:Bandwidth and Quality Factor

Lecture53:RLC ADS simulation

Lecture54:Two component networks

Lecture55:Low Quality Factor Example

Lecture56:Matching Circuit



此课程面向哪些人：

Electrical Engineers

RF Engineers

Communication Engineers

IoT Engineers

Hardware Engineers

Sales and Application Engineers

Semiconductor Employees

Engineers and Technicians seeking jobs in the RF Field
